Product Description
EF-1070 Start Solenoid for various SPX Stone power units.
- Dual-voltage 12/24VDC
- Rated for use up to 300 amps (intermittent), completely sealed construction eliminates need for circuit breakers, fuses or microswitches.
- Non-weldable contacts, interchangeable with current designs
- Neat one-plug wiring harness, terminals can not be over-tightened, covers single and double terminal applications
- Waterproofed to IP67, electronics suitable for use in ambient temperatures between -40°F (-40°C) and 185°F (86°C).
Replaces National Lift Gate # APL-3050, used on DM-1002. Also replaces old part # EF-1071. The only difference between the EF-1070 and EF-1071 was that the EF-1071 had an LED indicator light, while this EF-1070 does not.
Order with handset KG11A, KG12A, & KG13A.
For 24VDC, use 3467–AA wiring adaptor (not included).
We are an authorized SPX distributor!
EF1070, EF-1071, APL3050, DM1002
